TC1433 Overload Protection Tap Collet M14-M33 (ISO/JIS)

Tapping chuck/holder M14-M33 for quick-change tap holding with overload protection. 28 catalogue models. Factory-direct from NBD (Beijing Shuangfengli) — custom sizes on request.

SKU: ISO-TC1433-M14 Category: Tags: ,

Description

The TC1433 Overload Protection Tap Collet M14-M33 (ISO/JIS) is part of NBD’s tapping tool holder line for CNC machining centers, tapping machines, drill presses and lathes, designed for quick-change tap holding with overload protection. Tapping range M14-M33 with 28 catalogue models.

Features

  • High precision, long tool-life with torque protection function.
  • Torsion reflect sensitive and changes according to various
  • Used for kinds of tapping machine including electric
  • At present, many tapping machine factories have been

Model Naming

Model = Standard prefix (ISO/JIS) + collet size (GT12/GT24/GT42 or TC312/TC820/TC1433) + tap size (e.g. M12); d = tap shank dia., W = tap square.

Specification

Model Spec Dimensions (mm)
ISO-TC1433-M14 M14 11.2 9X9
ISO-TC1433-M16 M16 12.5 10X10
ISO-TC1433-M18 M18 14 11.2X11.2
ISO-TC1433-M20 M20 14 11.2X11.2
ISO-TC1433-M22 M22 16 12.5X12.5
ISO-TC1433-M24 M24 18 14X14
ISO-TC1433-M27 M27 20 16X16
ISO-TC1433-M30 M30 20 16X16
ISO-TC1433-M33 M33 22.4 18X18
ISO-TC1433-M36 M36 25 20X20
ISO-TC1433-M39 M39 28 22.4X22.4
ISO-TC1433-M42 M42 28 22.4X22.4
ISO-TC1433-M45 M45 31.5 25X25
ISO-TC1433-M48 M48 31.5 25X25
JIS-TC1433-M14 M14 10.5 8X8
JIS-TC1433-M16 M16 12.5 10X10
JIS-TC1433-M18 M18 14 11X11
JIS-TC1433-M20 M20 15 12X12
JIS-TC1433-M22 M22 17 13X13
JIS-TC1433-M24 M24 19 15X15
JIS-TC1433-M27 M27 20 15X15
JIS-TC1433-M30 M30 23 17X17
JIS-TC1433-M33 M33 25 19X19
JIS-TC1433-M36 M36 28 21X21
JIS-TC1433-M39 M39 30 23X23
JIS-TC1433-M42 M42 32 26X26
JIS-TC1433-M45 M45 35 26X26
JIS-TC1433-M48 M48 38 29X29

All dimensions in mm. Custom sizes and other interfaces on request — send us your drawing for a fast quote.

NBD (Beijing Shuangfengli Technology Co., Ltd.) manufactures CNC tool holders, tapping chucks and workholding with short lead times and factory-direct support for worldwide distributors and end users.

FAQ

What is your minimum order quantity (MOQ)?

For standard models the MOQ is 1 piece, and single-piece sample orders are welcome. For customized products or large-volume orders, the MOQ is quoted per model and specification.

What is your lead time?

In-stock items are shipped within 3-7 days after payment. Made-to-order items take 15-60 days, depending on the model and quantity.

How do you ship the goods?

We ship by international express (DHL, FedEx, UPS, EMS) for small orders, and by sea for bulk orders. The shipping method is arranged according to customer requirements.

Do you support OEM / ODM?

Yes. We support both OEM and ODM, including private labeling and manufacturing strictly from customer drawings or samples.

What payment methods do you accept?

Our standard payment method is T/T (bank transfer).

What is the warranty period?

All our products come with a one-year warranty.

Additional information

Interface / Taper

C1433
Tapping Range

M14-M33
